| Model Name | Panasonic Lumix S5 II Mirrorless Camera |
| Lens Mount | Leica L |
| Sensor Resolution | Actual: 25.28 Megapixel |
| Effective: 24.2 Megapixel (6000 x 4000) | |
| Image Sensor | 35.6 x 23.8 mm (Full-Frame) CMOS |
| Image Stabilization | Sensor-Shift, 5-Axis |
| ISO Sensitivity Range | Photo/Video |
| 100 to 51,200 (Extended: 50 to 204,800) | |
| Continuous Shooting | Mechanical Shutter |
| Up to 9 fps for up to 200 Frames (Raw) / 300 Frames (JPEG) | |
| Electronic Shutter | |
| Up to 30 fps for up to 200 Frames (Raw) / 200 Frames (JPEG) | |
| Internal Recording Modes | H.264/H.265/MOV/MPEG-4 AVC 4:2:2/4:2:0 8/10-Bit |
| 5952 x 3968 at 23.98/24.00/25/29.97 fps [200 Mb/s] | |
| 5952 x 3136 at 23.98/24.00/25/29.97 fps [200 Mb/s] | |
| 5888 x 3312 at 23.98/24.00/25/29.97 fps [200 Mb/s] | |
| 4096 x 2160 at 23.98/24.00/25/29.97/47.95/48.00/50/59.94 fps [150 to 200 Mb/s] | |
| 3840 x 2160 at 23.98/24.00/25/29.97/47.95/48.00/50/59.94 fps [150 to 200 Mb/s] | |
| 1920 x 1080 at 23.98/24.00/25/29.97/47.95/48.00/50/59.94/100 fps [20 to 150 Mb/s] | |
| External Recording Modes | 12-Bit via HDMI |
| 5888 x 3312 at 23.98/25/29.97 fps | |
| Media/Memory Card Slot | Dual Slot: SD/SDHC/SDXC (UHS-II) |
| Video I/O | 1x HDMI (Unspecified Signal) Output |
| Audio I/O | 1x 1/8 / 3.5 mm TRS Stereo Headphone Output |
| 1x 1/8 / 3.5 mm TRS Stereo Microphone Input | |
| Power I/O | 1x USB-C Input/Output |
| Other I/O | 1x USB-C Data Input/Output (Shared with Power Input) |
| Wireless | 2.4 / 5 GHz Wi-Fi 5 (802.11ac) |
| Bluetooth 5.0 | |
| Display Type | Free-Angle Tilting Touchscreen LCD |
| Battery Type | 1x Rechargeable Lithium-Ion, 7.2 VDC, 2200 mAh (Approx. 370 Shots) |
| Imaging | |
| Lens Mount | Leica L |
| Sensor Resolution | Actual: 25.28 Megapixel |
| Effective: 24.2 Megapixel (6000 x 4000) | |
| Image Sensor | 35.6 x 23.8 mm (Full-Frame) CMOS |
| Sensor Crop (35mm Equivalent) | Crop Factor: 1x |
| Additional Modes: 1.5x | |
| *Additional Crop Occurs in Select Video Modes | |
| Image Stabilization | Sensor-Shift, 5-Axis |
| Built-In ND Filter | No |
| Capture Type | Stills & Video |
| Exposure Control | |
| Shutter Type | Mechanical Focal Plane Shutter and Electronic Rolling Shutter |
| Shutter Speed | Mechanical Shutter |
| 1/8000 to 60 Seconds | |
| Up to 30 Minutes in Bulb Mode | |
| Electronic Front Curtain Shutter | |
| 1/2000 to 60 Seconds | |
| Up to 30 Minutes in Bulb Mode | |
| Electronic Shutter | |
| 1/8000 to 60 Seconds | |
| Up to 60 Seconds in Bulb Mode | |
| Bulb/Time Mode | Bulb Mode, Time Mode |
| ISO Sensitivity Range | Photo/Video |
| 100 to 51,200 (Extended: 50 to 204,800) | |
| Metering Method | Center-Weighted Average, Highlight Weighted, Multiple, Spot |
| Precise Scan Rate Control | Yes |
| Exposure Modes | Aperture Priority, Auto, Manual, Program, Shutter Priority |
| Exposure Compensation | -5 to +5 EV (1/3 EV Steps) |
| Metering Range | 0 to 18 EV |
| White Balance | 2500 to 10,000K |
| Presets: AWB, Cloudy, Color Temperature, Daylight, Flash, Incandescent, Shade, White Set 1, White Set 2, White Set 3, White Set 4 | |
| Continuous Shooting | Mechanical Shutter |
| Up to 9 fps for up to 200 Frames (Raw) / 300 Frames (JPEG) | |
| Electronic Shutter | |
| Up to 30 fps for up to 200 Frames (Raw) / 200 Frames (JPEG) | |
| Interval Recording | Yes |
| Self-Timer | 2/10-Second Delay |
| Still Image Capture | |
| Image Sizes | 0.126388888888889 |
| 96 MP (12,000 x 8000) *Via In-Camera Pixel-Shift | |
| 48 MP (8496 x 5664) *Via In-Camera Pixel-Shift | |
| 24 MP (6000 x 4000) | |
| 12 MP (4272 x 2848) | |
| 6 MP (3024 x 2016) | |
| 0.16875 | |
| 85 MP (10,656 x 8000) *Via In-Camera Pixel-Shift | |
| 42.5 MP (7552 x 5664) *Via In-Camera Pixel-Shift | |
| 21.5 MP (5328 x 4000) | |
| 10.5 MP (3792 x 2848) | |
| 5.5 MP (2688 x 2016) | |
| 0.672916666666667 | |
| 81 MP (12,000 x 6736) *Via In-Camera Pixel-Shift | |
| 40.5 MP (8496 x 4784) *Via In-Camera Pixel-Shift | |
| 20 MP (6000 x 3368) | |
| 10 MP (4272 x 2400) | |
| 5 MP (3024 x 1704) | |
| 0.0423611111111111 | |
| 64 MP (8000 x 8000) *Via In-Camera Pixel-Shift | |
| 32 MP (5664 x 5664) *Via In-Camera Pixel-Shift | |
| 16 MP (4000 x 4000) | |
| 8 MP (2848 x 2848) | |
| 4 MP (2016 x 2016) | |
| 2.725 | |
| 13 MP (6000 x 2208) | |
| 0.0840277777777778 | |
| 18 MP (6000 x 3000) | |
| Aspect Ratio | 1:1, 2:1, 3:2, 4:3, 16:9, 65:24 |
| Image File Format | JPEG, Raw |
| Bit Depth | 14-Bit |
| Video Capture | |
| Internal Recording Modes | H.264/H.265/MOV/MPEG-4 AVC 4:2:2/4:2:0 8/10-Bit |
| 5952 x 3968 at 23.98/24.00/25/29.97 fps [200 Mb/s] | |
| 5952 x 3136 at 23.98/24.00/25/29.97 fps [200 Mb/s] | |
| 5888 x 3312 at 23.98/24.00/25/29.97 fps [200 Mb/s] | |
| 4096 x 2160 at 23.98/24.00/25/29.97/47.95/48.00/50/59.94 fps [150 to 200 Mb/s] | |
| 3840 x 2160 at 23.98/24.00/25/29.97/47.95/48.00/50/59.94 fps [150 to 200 Mb/s] | |
| 1920 x 1080 at 23.98/24.00/25/29.97/47.95/48.00/50/59.94/100 fps [20 to 150 Mb/s] | |
| External Recording Modes | 12-Bit via HDMI |
| 5888 x 3312 at 23.98/25/29.97 fps | |
| Fast-/Slow-Motion Support | Yes |
| Gamma Curve | Panasonic V-Gamut, V-Log |
| Recording Limit | No |
| Broadcast Output | NTSC/PAL |
| IP Streaming | No |
| Built-In Microphone | Stereo |
| Audio Recording | MOV: 2-Channel 24-Bit 48 kHz LPCM Audio |
| MP4: 2-Channel 16-Bit 48 kHz AAC Audio | |
| Interface | |
| Media/Memory Card Slot | Dual Slot: SD/SDHC/SDXC (UHS-II) |
| Video I/O | 1x HDMI (Unspecified Signal) Output |
| Audio I/O | 1x 1/8 / 3.5 mm TRS Stereo Headphone Output |
| 1x 1/8 / 3.5 mm TRS Stereo Microphone Input | |
| Power I/O | 1x USB-C Input/Output |
| Other I/O | 1x USB-C Data Input/Output (Shared with Power Input) |
| Wireless | 2.4 / 5 GHz Wi-Fi 5 (802.11ac) |
| Bluetooth 5.0 | |
| Mobile App Compatible | Yes: Android & iOS |
| App Name: Lumix Sync | |
| Functionality: Access Stored Files, Firmware Update, Remote Control | |
| Global Positioning (GPS, GLONASS, etc.) | GPS |
| *Via Connected Smartphone | |
| Monitor | |
| Display Size | 3 |
| Resolution | 1,840,000 Dot |
| Display Type | Free-Angle Tilting Touchscreen LCD |
| Viewfinder | |
| Type | Built-In Electronic (OLED) |
| Resolution | 3,680,000 Dot |
| Eye Point | 21 mm |
| Coverage | 1 |
| Magnification | Approx. 0.78x |
| Diopter Adjustment | -4 to +2 |
| Focus | |
| Focus Type | Auto and Manual Focus |
| Focus Mode | Continuous-Servo AF, Manual Focus, Single-Servo AF |
| Autofocus Points | Photo, Video |
| Contrast Detection, Phase Detection: 779 | |
| Autofocus Sensitivity | -6 to +18 EV |
| Flash | |
| Built-In Flash/Light | No |
| Flash Modes | Auto, Auto/Red-Eye Reduction, Forced On, Forced On/Red-Eye Reduction, Slow Sync, Slow Sync/Red-Eye Reduction |
| Maximum Sync Speed | 1/250 Second |
| Flash Compensation | -3 to +3 EV (1/3 EV Steps) |
| Dedicated Flash System | TTL |
| External Flash Connection | Shoe Mount |
| Environmental | |
| Operating Temperature | 32 to 104°F / 0 to 40°C |
| Operating Humidity | 10 to 80% |
| General | |
| Battery Type | 1x Rechargeable Lithium-Ion, 7.2 VDC, 2200 mAh (Approx. 370 Shots) |
| Shoe Mount | 1x Hot Shoe |
| Tripod Mounting Thread | 1x 1/4-20 Female (Bottom) |
| Material of Construction | Magnesium Alloy |
| Dimensions (W x H x D) | 5.29 x 4.03 x 3.55 / 13.44 x 10.24 x 9.02 cm (Without Protrusions) |
| Weight | 1.45 lb / 658 g (Body Only) |
| 1.64 lb / 744 g (With Recording Media) | |
| Packaging Info | |
| Package Weight | 2.65 lb |
| Box Dimensions (LxWxH) | 13.4 x 7.4 x 6.6 |
