Model Name |
ILME-FX6V E-Mount Body |
Lens Mount |
Sony E |
Sensor Resolution |
Actual: 12.9 Megapixel |
|
Effective: 10.2 Megapixel |
Image Sensor |
Full-Frame CMOS |
Image Stabilization |
Supplies Stabilization Metadata |
ISO Sensitivity Range |
800 to 12,800 (Extended: 409,600) |
Internal Recording Modes |
XAVC-I |
|
DCI 4K (4096 x 2160) up to 59.94 fps [240 to 600 Mb/s VBR] |
|
UHD 4K (3840 x 2160) up to 59.94/100/120 fps [240 to 600 Mb/s VBR] |
|
1920 x 1080p up to 59.94/100/120/150/200/240 fps [89 to 223 Mb/s VBR] |
|
XAVC-L |
|
UHD 4K (3840 x 2160) up to 59.94/100/120 fps [100 to 150 Mb/s] |
|
1920 x 1080p up to 59.94/100/120/150/200/240 fps [35 to 50 Mb/s] |
|
Show More |
External Recording Modes |
Raw 16-Bit via SDI/BNC |
|
4096 x 2160 at 23.98/24.00/25/29.97/50/59.94 fps |
|
3840 x 2160 at 23.98/24.00/25/29.97/50/59.94 fps |
|
Raw 16-Bit via HDMI |
|
4264 x 2408 at 23.98/25/29.97/50/59.94 fps |
|
4240 x 2385 at 23.98/25/29.97/50/59.94 fps |
|
Show More |
Media/Memory Card Slot |
Dual Slot: CFexpress Type A / SD |
Video I/O |
1x BNC (12G-SDI) Output |
|
1x HDMI 1.0 Output |
Mobile App Compatible |
Yes: Android & iOS |
|
App Name: Content Browser Moblie |
Battery Type |
Sony BP-U Series |
Imaging |
|
Lens Mount |
Sony E |
Lens Communication |
Yes, with Autofocus Support |
Sensor Resolution |
Actual: 12.9 Megapixel |
|
Effective: 10.2 Megapixel |
Image Sensor |
Full-Frame CMOS |
Image Stabilization |
Supplies Stabilization Metadata |
Built-In ND Filter |
2 to 7 Stop Electronic ND Filter |
Internal Filter Holder |
No |
Capture Type |
Video Only |
Exposure Control |
|
Shutter Type |
Electronic Rolling Shutter |
Shutter Type |
Electronic Rolling Shutter |
Shutter Speed |
1/8000 to 1 Second |
ISO Sensitivity Range |
800 to 12,800 (Extended: 409,600) |
Gain |
-3 to 30 dB (Native) |
Shutter Angle |
5.6 to 360° |
Advertised Dynamic Range |
15 Stops |
White Balance |
2000 to 15,000K |
|
Presets: ATW, Set A, Set B |
Video Capture |
|
Internal Recording Modes |
XAVC-I |
|
DCI 4K (4096 x 2160) up to 59.94 fps [240 to 600 Mb/s VBR] |
|
UHD 4K (3840 x 2160) up to 59.94/100/120 fps [240 to 600 Mb/s VBR] |
|
1920 x 1080p up to 59.94/100/120/150/200/240 fps [89 to 223 Mb/s VBR] |
|
XAVC-L |
|
UHD 4K (3840 x 2160) up to 59.94/100/120 fps [100 to 150 Mb/s] |
|
1920 x 1080p up to 59.94/100/120/150/200/240 fps [35 to 50 Mb/s] |
External Recording Modes |
Raw 16-Bit via SDI/BNC |
|
4096 x 2160 at 23.98/24.00/25/29.97/50/59.94 fps |
|
3840 x 2160 at 23.98/24.00/25/29.97/50/59.94 fps |
|
Raw 16-Bit via HDMI |
|
4264 x 2408 at 23.98/25/29.97/50/59.94 fps |
|
4240 x 2385 at 23.98/25/29.97/50/59.94 fps |
Sensor Crop While Recording |
3840 x 2160 When Recording in Raw / Slow-Mo |
Fast-/Slow-Motion Support |
Yes |
Gamma Curve |
HDR-HLG, Rec709, S Cinetone, Sony S-Log 3, Standard |
Built-In Microphone |
Mono |
Audio Recording |
4-Channel 24-Bit 48 kHz LPCM Audio |
IP Streaming |
Yes |
Interface |
|
Media/Memory Card Slot |
Dual Slot: CFexpress Type A / SD |
Video I/O |
1x BNC (12G-SDI) Output |
|
1x HDMI 1.0 Output |
Audio I/O |
2x XLR 3-Pin Mic/Line (+48 V Phantom Power) Input on Included Handle |
|
1x 1/8 / 3.5 mm TRS Stereo Microphone Output |
Power I/O |
1x Barrel (19.5VDC) Input |
Other I/O |
1x USB-C (USB 3.2 / 3.1 Gen 1) |
|
1x Sony Multi/Micro-USB Data |
|
1x BNC (Timecode) |
|
1x 2.5 mm Sub-Mini Control |
|
1x 1/8 / 3.5 mm Control |
|
1x Proprietary |
Wireless |
2.4 / 5 GHz Wi-Fi 5 (802.11ac), NFC |
Mobile App Compatible |
Yes: Android & iOS |
|
App Name: Content Browser Moblie |
Global Positioning (GPS, GLONASS, etc.) |
No |
Monitor |
|
Display Size |
3.5 |
Resolution |
1280 x 720 (2,760,000 Dot) |
Display Type |
Included External Touchscreen LCD |
Viewfinder |
|
Type |
Optional, Not Included |
Focus |
|
Focus Type |
Auto and Manual Focus |
Autofocus Points |
Phase Detection: 627 |
Environmental |
|
Operating Temperature |
32 to 104°F / 0 to 40°C |
Storage Temperature |
-4 to 140°F / -20 to 60°C |
General |
|
Battery Type |
Sony BP-U Series |
Power Consumption |
18 W |
Shoe Mount |
1x Intelligent Hot Shoe |
Tripod Mounting Thread |
1x 1/4-20 Female |
|
1x 3/8-16 Female |
Accessory Mounting Thread |
10x 1/4-20 on Camera Body |
|
7x 1/4-20 on Included Handle |
Netflix Approved |
Yes |
Material of Construction |
Magnesium Alloy |
Dimensions (W x H x D) |
6.02 x 4.57 x 4.49 / 15.29 x 11.61 x 11.4 cm (Without Protrusions) |
Weight |
2.0 lb / 890 g (Body Only) |
|
5.71 lb / 2.59 kg (With Battery, Grip, Handle, Viewfinder) |
Packaging Info |
|
Package Weight |
7.99 lb |
Box Dimensions (LxWxH) |
12.4 x 11.6 x 10.2 |
